System requirements and Specs:
Mac OS 10.11 and above | Class-Compliant, Plug-and-play
Windows 10, Windows 11 | Install included ASIO/WDM driver
USB 2.0 Type C Connector (Box includes Type C to C and Type C to A)
-130.5 dBu EIN
Gain Range: 62 dB
Max Instrument Input Level: +15 dBu
Max Line Input Level: +24 dBu
*Specs (Measured to AES17 Standards)
Dynamic Range: 112 dB
Max Output Level: + 12.5 dBu
Dynamic Range: 111 dB
Max Output: +10 dBu
44.1, 48, 88.2, 96, 176.4, 192 kHz
ASIO is a trademark and software of Steinberg Media Technologies GmbH
Legacy 4K – Analogue Enhancement
Real analogue enhancement inspired by SSL 4000 series (4K) console
SSL has a history of innovation in analogue electronics and console design. Whether it be the sound of our classic EQ ‘242’ and ‘292’ EQ circuits, the punch of the legendary SSL G-Series Bus Compressor or the incredible bandwidth and sonic accuracy of our ground-breaking SuperAnalogue designed mic amps and consoles, we’re always moving forward with analogue.
Legacy 4K is an all-new analogue enhancement effect, inspired by the character of an SSL 4000 series console (often referred to as ‘4K’). With the Legacy 4K button, we’ve distilled 2 essential characteristics of the 4K sound into a single-circuit, which you can engage when you need to breath some life into ‘boring’ or ‘dull’ sounding input sources.
1st characteristic: High-Frequency EQ boost – The first thing engaging the Legacy 4K button will do is introduce a ‘forward’, yet musical high-frequency EQ boost, something which 4000-series EQs are known and loved for.
2nd characteristic: Subtle-Harmonic Distortion – 4K consoles are synonymous with imparting a certain ‘mojo’ to signals passing through them. This mojo comes through multiple stages of harmonic distortion from compressor VCAs, VCA Faders and other crucial areas like the transistor mix amps. Using modern components, we’ve created a circuit that injects a controlled amount of finely-tuned, sweet- sounding harmonic distortion into the signal path, helping to give your sound more edge!
